This GUANDN Vacuum Oven, also known as a vacuum drying oven, is specially designed for heat-sensitive and oxidation-prone materials, suitable for vacuum drying, degassing, and curing processes in electronics, pharmaceuticals, chemicals, and material sciences.<br /> <br /> >It processes samples in oxygen-free or low-oxygen environments, effectively preventing oxidation, decomposition, or contamination.<br /> >Widely used in high-end manufacturing fields such as lithium battery materials, semiconductor packaging, and precision ceramics.
Inert gas valve:Nitrogen/argon gas can be passed to achieve inert atmosphere protection
Multistage vacuum pump:rotary vane pump + molecular pump combination to obtain a higher vacuum degree
Corrosion resistant: PTFE coated inner liner, suitable for acidic/solvent environments
Multi-layer tray:304 stainless steel adjustable shelf, bearing capacity up to 20kg
Automatic interface:Support with glove box, automatic production line docking
| Model number | Effective volume (L) | Vacuum degree | Temperature range | Power (KW) | Power source |
| GD-V-30 | 30 | -0.098MPa | RT~250℃ | 1.5 | 220V |
| GD-V-60 | 60 | -0.098MPa | RT~250℃ | 2.2 | 220V |
| GD-V-120 | 120 | -0.1MPa | RT~300℃ | 3.8 | 380 |
| custom | 10~500L | custom | RT~400℃ | As needed | custom |
1Consultation Share your specs: temperature range, throughput, automation needs.
2 Design and Development Interactive CAD models delivered.
3 Prototype Testing On-site trials with your actual materials at our facility.
4 Mass Production Full documentation package with certifications.
5DeliveryTransportation and after-sales service
GUANDN will design equipment based on your production volume, temperature needs (30–2200°C), automation requirements, footprint needs, and more.
From the initial design concept, production, to after - sales service, Our team of experienced engineers, with over 15 years of design experience on average, will work closely with you to provide CAD design, 3D layout, and max temp thermal simulation.
Share your specs—we’ll design, optimize, and deliver.
