This GUANDN laboratory oven is designed for laboratory R&D, small-batch production, and quality testing, suitable for precise processes such as material drying, heat treatment, aging tests, and electronic component curing.<br /> Widely used in universities, research institutes, pharmaceuticals, electronics, and chemical laboratories.<br /> Temperature range: ambient to 300℃, meeting most laboratory heat treatment requirements.
Data recording:USB interface, real-time record temperature curve, support data export
Gas interface:Optional nitrogen/inert gas access for special atmosphere experiments
Explosion-proof design:Suitable for handling flammable and explosive samples (need to be customized)
Multi-layer shelf:Adjustable stainless steel shelf, flexible space allocation
Remote monitoring: real-time monitoring of equipment status through the computer
| Model number | Internal dimension(mm) | Temperature range | Power (KW) | Temperature control accuracy | Power source |
| GD-80 | 450×450×450 | Room temperature ~300℃ | 1.8 | ±1℃ | 220V |
| GD-150 | 600×600×600 | Room temperature ~300℃ | 3.0 | ±1℃ | 220V |
| GD-250 | 800×800×800 | Room temperature ~300℃ | 5.0 | ±1.5℃ | 380 |
| custom | On-demand design | Room temperature ~300℃ | custom | Plus or minus 0.5 ~ 1.5 ℃ | custom |
1Consultation Share your specs: temperature range, throughput, automation needs.
2 Design and Development Interactive CAD models delivered.
3 Prototype Testing On-site trials with your actual materials at our facility.
4 Mass Production Full documentation package with certifications.
5DeliveryTransportation and after-sales service
GUANDN will design equipment based on your production volume, temperature needs (30–2200°C), automation requirements, footprint needs, and more.
From the initial design concept, production, to after - sales service, Our team of experienced engineers, with over 15 years of design experience on average, will work closely with you to provide CAD design, 3D layout, and max temp thermal simulation.
Share your specs—we’ll design, optimize, and deliver.
